APC SRV2KI Easy UPS On-Line 2000VA/1600W UPS with Intelligent Card Slot

APCSKU: SRV2KI

APC by Schneider Electric Easy UPS SRV2KI Double Conversion Online UPS - 2 kVA/1.60 kW - Tower - 4 Hour Recharge - 4 Minute Stand-by - 230 V AC Input - 220 V AC Output - 4 x IEC 60320 C13 - Single Phase - Serial Port

Availability:

❌ Back Order - Contact Us for ETA

Price:
Sale price$1,225.00
Contact Us for ETA

Estimate shipping

APC Easy UPS On-Line SRV2KI
This APC Single phase Easy UPS is designed for IT professionals or network administrators to maintain business uptime and continuity.

APC Easy UPS Online is a versatile, high quality, cost competitive UPS developed to handle a wide voltage range and inconsistent power conditions. High quality, Double-conversion for essential power protection needs even in the most unstable power conditions. That's Certainty in a Connected World.

  • 1600 Watt Output Power Capacity
  • 4 Power Sockets (C13)
Because Life Always Needs to be On.
Provide an emergency power supply for your electrical equipment to protect your investment from unexpected power disruption, including spikes, surges and voltage dips.
Power Surge Protection: Stabilises the main electrical line voltage to your devices.
Refined Power Supply: Protects connected devices from dips and spikes caused by lightning.
Instant Power: Power to your equipment the exact moment the power goes out, protecting you from data loss or unexpected interruption.
Ensure reliable uptime and clean power for your critical devices.
UPS

Protect Your Investment

APC Easy UPS are quality products for price-conscious customers, helping to provide power protection and backup in unstable power conditions, and consistent and reliable connectivity at critical moments. Providing real output power to support equipment during outages as well as automatic Voltage Regulation (AVR) correcting utility voltage dips and surges.

Excellent Power Quality and Performance

True Double Conversion provides tight voltage, frequency regulation and zero transfer time for reactive loads. Protects connected loads from surges, spikes, lightning and other power disturbances.

Business Owner

Additional Features

LCD display screen

LCD interface provides clear information with the ability to configure the UPS locally with easy to use navigation keys.

Emergency power off

Immediately remove power to all connected equipment in the event of an emergency. Built-in automatic bypass ensures seamless power to the load even in the event of catastrophic failure.

Understand Your Device Runtime

Using the below table, you can choose a solution aligned with your specific application and runtime needs to ensure you’re protected.

Application
SRV1KI
SRV2KI
SRV3KI
300 Watts
15 mins
36 mins
63 mins
600 Watts
6 mins
16 mins
29 mins
900 Watts
-
10 mins
18 mins
1200 Watts
-
6 mins
12 mins

Runtime varies according to devices, usage and power settings. The higher battery power (VA), the longer the runtime provided.

Smart-UPS Cloud-enabled Management Options

The On-Line UPS has an intelligent card slot for optional Network Management Card* that enables network-based UPS monitoring and management. The UPS can connect to EcoStruxure IT or third-party centralised management platforms.

EcoStruxure IT

IT Expert

Monitoring

Eco

IT Expert helps the IT Professional manage their IT equipment for Local Edge and Distributed IT. It synthesises performance and alarming data into proactive recommendations and enables secure, wherever-you-go visibility.

IT Advisor

Planning and Modeling

Eco

IT Advisor is an asset planning tool that enables Data Center Managers to reduce OPEX, plan for uptime and automate reporting by optimising capacities, analysing business impact, automating workflow and deploying energy-based billing.

Asset Advisor

24/7 Monitoring

Eco

Asset Advisor provides a remote monitoring service for your critical equipment, increasing Resiliency and quick resolution through Schneider Electric’s service personnel equipped with real-time device data to quickly troubleshoot and dispatch.

* Network Management Card (AP9544, SRVSMB001, VGL9601l) sold separately.

Impact Company
Green Premium

Sustainability is at the heart of our strategy.

At Schneider Electric, sustainability has been at the core of our business strategy for the past 15 years. Being awarded with top rating in four keys Environmental, Social and Governance corporate ratings, demonstrates our sustainability leadership which has spanned over a decade (DJSI, Ecovadis, CDP A list, Vigeo Eiris). As an impact company, we create technologies and solutions to advance a more efficient, sustainable, resilient, and inclusive world for all. We work with customers, partners, governments, and suppliers to deploy these solutions and create a low-carbon future.


Technical Specifications
Main
Main Input Voltage

230 V

Other Input Voltage

220 V
240 V

Main Output Voltage

230 V

Other Output Voltage

220 V
240 V

Rated power in W

1600 W

Rated power in VA

2000 VA

Input Connection Type

IEC 60320 C14

Output connection type

4 IEC 60320 C13

Cable length

1.50 m

Number of cables

1

Provided equipment

1 IEC 60320 C13 to Schuko power cable
1 IEC 60320 C13 to C14 power cable
1 USB cable
1 RS-232 configuration cable
User manual

General
Max runtime

4 min

Number of power module filled slots

0

Number of power module free slots

0

Redundant

No

Physical
Colour

Black (RAL 7010)

Height

23.8 cm

Width

14.5 cm

Depth

40 cm

Net weight

16.8 kg

Mounting location

Front

Mounting preference

No preference

Mounting mode

Not rack-mountable

USB compatible

Yes

Mounting position

Vertical

Input
Input voltage limits

110 - 285 V half load
160 - 280 V full load

Network frequency

40 - 70 Hz auto-sensing

Output
Maximum configurable power in VA

2000 VA

Maximum configurable power in W

1600 W

Output frequency

50/60 Hz +/- 3 Hz sync to mains

Harmonic distortion

3%

UPS type

Double conversion online

Wave type

Sine wave

Efficiency

88% (full load)

Additional information

Configurable for 220 : 230 or 240 nominal output voltage

Bypass type

Internal bypass (automatic and manual)

Crest factor

3 : 1

Conformance
Product certifications

CE
UKCA
EAC
TISI

Standards

EN/IEC 62040-1:2019/A11:2021
EN/IEC 62040-2:2006/AC:2006
EN/IEC 62040-2:2018

Environmental
Ambient air temperature for operation

0 - 40°C

Relative humidity

0 - 95% non-condensing

Operating altitude

0 - 3000m

Ambient air temperature for storage

-20 - 50°C

Storage Relative Humidity

0 - 95% non-condensing

Storage altitude

0.00 - 15000m

Acoustic level

50 dBA

Heat dissipation

745 Btu/h

IP degree of protection

IP20

Batteries & Runtime
Battery type

Lead-acid battery

Battery voltage

48 V

Number of battery filled slots

0

Number of battery free slots

0

Battery recharge time

4 h

Battery life

3 - 5 year(s)

Replacement battery

APCRBCV204

Battery charger power

70 W rated

Communications & Management
Alarm

Alarm when on battery : distinctive low battery alarm : overload continuous tone alarm

Control panel

Multifunction LCD status and control console

Surge Protection And Filtering
Surge energy rate

600 J

Contractual Warranty
Warranty

2 years repair or replace



Automatic internal bypass
Supplies utility power to the connected loads in the event of a UPS power overload or fault.

Automatic restart of loads after UPS shutdown
Automatically starts up the connected equipment upon the return of utility power.

ECO Mode
Operating mode that by-passes unused electrical components in good power conditions to achieve high operating efficiency without sacrificing protection

Input power factor correction
Minimizes installation costs by enabling the use of smaller generators and cabling.

Intelligent battery management
Maximizes battery performance, life, and reliability through intelligent, precision charging.

LCD graphics display
Text and mimic diagrams that display modes of operation, system parameters and alarms.

Serial connectivity
Provides management of the UPS via a serial port.

USB connectivity
Provides management of the UPS via a USB port (not available on all models).

Technical Specifications

Output

Max Configurable Power (Watts)
1.6kWatts / 2.0kVA

Output Voltage Note
Configurable for 220 : 230 or 240 nominal output voltage

Efficiency at Full Load
88.0 %

Output Frequency (sync to mains)
50/60Hz +/- 3 Hz

Other Output Voltages
220, 240

Load Crest Factor
3 : 1

Topology
Double Conversion Online

Waveform type
Sine wave

Transfer Time
4ms typical

Bypass
Internal Bypass (Automatic and Manual)

Input

Input frequency
40 - 70 Hz

Input voltage range for main operations
160 - 280V

Input voltage adjustable range for mains operation
100 - 280 (half load)V

Number of Power Cords
1

Efficiency at Full Load
88.0 %

Other Input Voltages
220, 240

Batteries & Runtime

Battery type
Maintenance-free sealed Lead-Acid battery with suspended electrolyte : leakproof

Typical recharge time
4hour(s)

Battery Charge Power (Watts)
76Watts

Battery Volt-Amp-Hour Capacity
304

Communications & Management

Interface Port(s)
DB-9 RS-232, Smart-Slot, USB

Control panel
Multi-function LCD status and control console

Audible Alarm
Alarm when on battery : distinctive low battery alarm : overload continuous tone alarm

Available SmartSlot™ Interface Quantity
1

Surge Protection and Filtering

Surge energy rating
600Joules

Physical

Maximum Height
238MM, 23.8CM

Maximum Width
145MM, 14.5CM

Maximum Depth
400MM, 40.0CM

Net Weight
16.8KG

Shipping weight
18.1KG

Shipping Height
355MM, 35.5CM

Shipping Width
235MM, 23.5CM

Shipping Depth
525MM, 52.5CM

Color
Black

Environmental

Operating Temperature
0 - 40 °C

Operating Relative Humidity
0 - 95 (non-condensing) %

Operating Elevation
0-3000meters

Storage Temperature
-20 - 50 °C

Storage Relative Humidity
0 - 95 (non-condensing) %

Storage Elevation
0-15000meters

Audible noise at 1 meter from surface of unit
50.0dBA

Protection Class
IP 20

Conformance

Approvals
CE, IEC 62040-1-1, IEC 62040-1-2

Sustainable Offer Status
RoHS

Compliant

REACH
REACH: Contains No SVHCs
