Description
ASUS Pro WS W790E-SAGE SE
Intel® W790 (LGA 4677) EEB workstation motherboard, PCIe 5.0 x16, M.2, Dual 10G LAN, Server-grade Remote Management, 14+1+1 power stages, USB 3.2 Gen 2x2 Type-C®
- Intel® LGA 4677 socket: Ready for Intel Xeon® W-3400 & W-2400 processors
- CPU and memory overclocking: Supports for up to 2TB of ECC R-DIMM DDR5 memory (1DPC)
- Ultrafast connectivity: 7 PCIe 5.0 x16 slots, Dual Intel X710-AT2 10G LAN, 3 M.2, USB 3.2 Gen 2x2 Type-C® and 2 SlimSAS
- Server-grade IPMI remote management: Hardware and software-level with a dedicated LAN port link to AST2600 BMC controller, plus a real-time monitoring and management software – ASUS Control Center Express
- Robust power and thermal design: 14+1+1 power stages, 8-pin and 6-pin PCIe power connectors, Massive VRM, chipset, M.2 heatsinks and M.2 backplates
- Trusted stability: Highly compatible with the latest technologies with solid QVL list and tested for 24/7 operation, validated for extensive compatibility
Specifications
Model | Pro WS W790E-SAGE SE |
CPU | - Intel® Socket LGA4677 for Xeon® W-3400 and W-2400 Series Processors* |
- Supports Intel® Turbo Boost Max Technology 3.0 | |
- Refer to ASUS website for CPU support list | |
Chipset | Intel® W790 Chipset |
Memory | - 8 x DIMM slots, Max. 2048GB, DDR5 6800(OC)/6600(OC)/6400(OC)/6200(OC)/6000(OC)/5800(OC)/5600(OC)/5400(OC)/5200(OC)/5000(OC)/4800 ECC Registered Memory* |
- 8-Channel Memory Architecture | |
- Supports Intel® Extreme Memory Profile (XMP) | |
- Supported memory types, data rate (speed), and number of DRAM modules vary depending on the CPU and memory configuration, for more information please refer to CPU/Memory Support list under the Support tab of product information site or visit ASUS support | |
Graphics | - 1 x VGA port from AST2600 |
Expansion Slots | Intel® Xeon® W-3400 Series Processors* |
- 7 x PCIe 5.0 slot(s) (Seven at x16/x16/x16/x16/x16/x8/x16)** | |
Storage | - Total supports 3 x M.2 slots, 2 x SlimSAS slots, and 8 x SATA 6Gb/s ports* |
Intel® Xeon® W-3400 Series Processors | |
- M.2_1 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 5.0 x4 mode)*** | |
- M.2_2 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 5.0 x4 mode)*** | |
Intel® W790 Chipset | |
- M.2_3 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 4.0 x4 mode) | |
- SlimSAS_1 port supports PCIe 4.0 x4 mode NVMe device | |
- SlimSAS_2 port supports PCIe 4.0 x4 mode NVMe device | |
- 8 x SATA 6Gb/s ports | |
- Supports Intel® Virtual RAID on CPU (Intel® VROC) and Intel Volume Management Device (Intel®VMD) | |
Ethernet | - 1 x Intel® dual 10Gb Ethernet |
- 1 x Realtek 1Gb Ethernet | |
- ASUS LANGuard | |
USB | Rear USB (Total 8 ports) |
- 1 x USB 3.2 Gen 2x2 port(s) (1 x USB Type-C®) | |
- 5 x USB 3.2 Gen 2 port(s) (4 x Type-A + 1 x USB Type-C®) | |
- 2 x USB 2.0 port(s) (2 x Type-A) | |
Front USB (Total 7 ports) | |
- 1 x USB 3.2 Gen 2 connector (supports USB Type-C® ) | |
- 1 x USB 3.2 Gen 1 header(s) support(s) 2 additional USB 3.2 Gen 1 ports | |
- 2 x USB 2.0 header(s) support(s) 4 additional USB 2.0 ports | |
Audio | - Realtek S1220A 7.1 Surround Sound High Definition Audio CODEC* |
- Impedance sense for front and rear headphone outputs | |
- Internal audio Amplifier to enhance the highest quality sound for headphone and speakers | |
- Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking | |
- High quality 120 dB SNR stereo playback output and 113 dB SNR recording input (Line-in) | |
- Supports up to 32-Bit/192 kHz playback* | |
Back Panel I/O Ports | - 1 x USB 3.2 Gen 2x2 port(s) (1 x USB Type-C) |
- 5 x USB 3.2 Gen 2 port(s) (4 x Type-A + 1 x USB Type-C®) | |
- 2 x USB 2.0 port(s) (2 x Type-A) | |
- 1 x VGA port | |
- 2 x Intel® dual 10Gb Ethernet ports | |
- 1 x Realtek 1Gb Ethernet port | |
- 5 x Audio jacks | |
- 1 x Optical S/PDIF out port | |
- 1 x BIOS FlashBack™ button | |
- 1 x Clear CMOS button | |
Internal I/O Connectors | Fan and Cooling related |
- 1 x 4-pin CPU Fan header(s) | |
- 1 x 4-pin CPU OPT Fan header(s) | |
- 5 x 4-pin Chassis Fan header(s) | |
- 1 x W_PUMP+ header(s) | |
Power related | |
- 2 x 24-pin Main Power connector | |
- 4 x 8-pin +12V Power connector | |
- 1 x 8-pin PCIe Power connector | |
- 1 x 6-pin PCIe Power connector | |
Storage related | |
- 3 x M.2 slots (Key M) | |
- 2 x SlimSAS connector(s) | |
- 8 x SATA 6Gb/s ports | |
- 1 x VROC Key connector | |
USB | |
- 1 x USB 3.2 Gen 2 connector (support(s) USB Type-C® ) | |
- 1 x USB 3.2 Gen 1 header(s) support(s) 2 additional USB 3.2 Gen 1 ports | |
- 2 x USB 2.0 header(s) support(s) 4 additional USB 2.0 ports | |
Miscellaneous | |
- 1 x COM Port header | |
- 1 x FlexKey button | |
- 1 x Front Panel Audio header (AAFP) | |
- 1 x LN2 Mode jumper | |
- 1 x M.2 slot (Key E) | |
- 1 x ReTry button | |
- 1 x Safe Boot button | |
- 1 x SPI TPM header (14-1pin) | |
- 1 x Start button | |
- 1 x 20-3 pin System Panel header with Chassis intrude function | |
- 1 x Thermal Sensor header | |
BMC Related | |
- 1 x BMC switch | |
- 1 x VGA switch | |
- 1 x BMC LAN fixed IP switch | |
- 1 x IPMI switch | |
- 2 x Q_PSU switch | |
- 2 x PSU SMBus header | |
- 1 x Front panel location LED header | |
- 1 x Location button header | |
- 1 x VPP_I2C header | |
- 1 x Micro SD card socket | |
- 1 x BMC_T_SENSOR header | |
- 1 x BMC LED | |
- 1 x Location LED | |
- 1 x Message LED header | |
Special Features | Extreme OC Kit |
- FlexKey button | |
- LN2 Mode | |
- ReTry button | |
- Safe boot button | |
- Start button | |
Extreme Engine Digi+ | |
- 10K Black Metallic Capacitors | |
- MicroFine Alloy Choke | |
ASUS 5X PROTECTION III | |
- DIGI+ VRM (- Digital power design with DrMOS) | |
- ESD Guards | |
- LANGuard | |
- Overvoltage Protection | |
- Safeslot | |
- Stainless-Steel Back I/O | |
ASUS Q-Design | |
- M.2 Q-Latch | |
- Q-Code | |
- Q-Connector | |
- Q-DIMM | |
- Q-LED (CPU [red], DRAM [yellow], VGA [white], Boot Device [yellow green]) | |
- Q-Slot | |
ASUS Thermal Solution | |
- M.2 heatsink backplate | |
- M.2 heatsink | |
- Steel backplate | |
- VRM heatsink design | |
ASUS EZ DIY | |
- BIOS FlashBack™ button | |
- BIOS FlashBack™ LED | |
- Caterr1 LED | |
- Box Headers | |
- Clear CMOS button | |
- ProCool II | |
- Pre-mounted I/O shield | |
- SafeSlot | |
- SafeDIMM | |
Bespoke Motherboard Design & Business Focused Features | |
- 24/7 Reliability | |
- Overcurrent Protection | |
Software Features | ASUS Exclusive Software |
- Armoury Crate | |
- Fan Xpert 4 | |
AI Suite 3 | |
- TPU | |
- DIGI+ VRM | |
- Turbo app | |
- PC Cleaner | |
ASUS CPU-Z | |
IT Management software supported | |
- ASUS Control Center Express(ACCE) | |
Included Software | |
- Adobe Creative Cloud (Free Trial) | |
- Norton 360 Deluxe (60 Days Free Trial) | |
- WinRAR | |
UEFI BIOS | |
ASUS EZ DIY | |
- ASUS CrashFree BIOS 3 | |
- ASUSTeK. EzFlash Utility | |
FlexKey | |
BIOS | - 512 Mb Flash ROM, UEFI AMI BIOS |
Manageability | - WOL by PME, PXE (UEFI mode) |
Accessories | Cables |
- 4 x SATA 6Gb/s cables | |
- 1 x Thermistor cable pack | |
Miscellaneous | |
- 1 x VRM Fan holder | |
- 1 x Q-connector | |
- 1 x M.2 Rubber Package(s) | |
- 1 x M.2 backplate Rubber Package(s) | |
- 1 x Screw package for M.2 Key E | |
- 1 x CPU guard for LGA 4677 E1A | |
- 1 x CPU guard for LGA 4677 E1B | |
Documentation | - 1 x ACC Express Activation Key Card |
- 1 x User guide | |
Operating System | - Windows® 11, Windows® 10 64-bit |
Form Factor | - EEB Form Factor |
- 12 inch x 13 inch (30.5 cm x 33 cm) |
