Cisco C9200L-24T-4X-E Catalyst 9200 24 Ports Manageable Switch 4x10G SFP, Network Essentials

CiscoSKU: C9200L-24T-4X-E

Cisco Catalyst 9200 24 Ports Manageable Layer 3 Switch - 3 Layer Supported - Modular - Twisted Pair, Optical Fiber

Availability:

❌ Back Order - Contact Us for ETA

Price:
Sale price$2,874.00
Contact Us for ETA

Customer Reviews

Be the first to write a review
0%
(0)
0%
(0)
0%
(0)
0%
(0)
0%
(0)

Description

Cisco Catalyst 9200 Series 24 Port Switch [C9200L-24T-4X-E]

Extend intent-based networking everywhere

Cisco® Catalyst® 9200 Series switches extend the power of intent-based networking and Catalyst 9000 hardware and software innovation to a broader set of deployments. With its family pedigree, Catalyst 9200 Series switches offer simplicity without compromise – it is secure, always on, and IT simplified.

As foundational building blocks for the Cisco Networking Cloud, Catalyst 9200 Series switches help customers simplify complexity, optimize IT, and reduce operational costs by leveraging intelligence, automation and human expertise that no other vendor can deliver regardless of where you are in the intent-based networking journey.

Catalyst 9200 Series switches provide security features that protect the integrity of the hardware as well as the software and all data that flows through the switch. It provides resiliency that keeps your business up and running seamlessly. Combine that with open APIs of Cisco IOS XE® and programmability of the UADP ASIC technology, Catalyst 9200 Series switches give you what you need now with investment protection on future innovations.

With full PoE+ capability, power and fan redundancy, stacking bandwidth up to 160 Gbps, modular uplinks, Layer 3 feature support, and cold patching, Catalyst 9200 Series switches are the industry’s unparalleled solution with differentiated resiliency and progressive architecture for cost-effective branch-office access. Catalyst 9200 Series switches also provide operational choice of CLI, Cisco Catalyst Center (formerly Cisco DNA Center) on-premises management, or cloud monitoring for Catalyst on Meraki dashboard.

Product overview

Product highlights

●      Full Power over Ethernet Plus (PoE+) capability for up to 48 ports for C9200. Power over Ethernet Plus (PoE+) capability for up to 12 ports, IEEE 802.3bt class 6 and Cisco UPOE capability for up to 8 ports for C9200CX.

●      Resiliency with Field-Replaceable Units (FRU) and redundant power supply, fans, and modular uplinks for C9200 models. C9200CX models are fanless and are powered by internal fixed power supply or optional power adapters, when not powered by upstream IEEE 802.3bt class 6 60W PSE.

●      Flexible power source options from line voltage AC, low voltage DC to High Voltage DC (HVDC) in C9200CX models provide the choices for customers to migrate to efficient DC micro grid powered by renewable energy sources for a sustainable future.

●      Flexible downlink options with data, PoE+, UPOE, UPOE with mGig for Wi-Fi 6/6E.

●      Operational efficiency with optional backplane stacking, supporting stacking bandwidth up to 160 Gbps.

●      UADP 2.0 Mini with integrated CPU offers customers optimized scale with better cost structure.

●      Enhanced security with AES-128 MACsec encryption on C9200 and AES-256 MACsec encryption for C9200CX models, policy-based segmentation, and trustworthy solutions for the whole Catalyst 9200 Series.

●      Layer 3 https://apps.cisco.com/Commerce/ and CLI operations options.

●      Cisco Software-Defined Access (SD-Access).

◦    Simplified operations and deployment with policy-based automation from edge to cloud managed with Cisco Identity Services Engine (ISE).

◦    Network assurance and improved resolution time through Cisco Catalyst Center.

●      Plug and Play (PnP) enabled: A simple, secure, unified, and integrated offering to ease new branch or campus device rollouts or updates to an existing network.

●      Cisco IOS XE: A Common Licensing based operating system for the enterprise Cisco Catalyst 9000 product family with support for model-driven programmability and streaming telemetry.

●      ASIC with programmable pipeline and micro-engine capabilities, along with template-based, configurable allocation of Layer 2 and Layer 3 forwarding, Access Control Lists (ACLs), and Quality of Service (QoS) entries.

●      Cloud monitoring for Catalyst on Meraki dashboard.

●      ENERGY STAR® certified models (C9200L models).



Specifications


Basic
Brand Name: Cisco
Ethernet Technology: 10 Gigabit Ethernet
Gigabit Ethernet
Expansion Slot Type: SFP+
Layer Supported: 3
Manageable: Yes
Media Type Supported: Twisted Pair
Network Technology: 10GBase-X
Number of Total Expansion Slots: 4
Port/Expansion Slot Details: 10 Gigabit Ethernet
Power Source: Power Supply
Product Family: Catalyst 9200
Product Type: Layer 3 Switch
Redundant Power Supply Supported: Yes
Stack Port: Yes
Total Number of Network Ports: 24

General Information
Brand Name: Cisco
Manufacturer Part Number: C9200L-24T-4X-E
Manufacturer Website Address: http://www.cisco.com/c/en_au
Manufacturer: Cisco Systems, Inc
Product Line: Catalyst
Product Model: C9200L-24T-4X
Product Name: Catalyst 9200 C9200L-24T-4X Layer 3 Switch
Product Series: 9200
Product Type: Layer 3 Switch

I/O Expansions
Expansion Slot Type: SFP+
Number of SFP+ Slots: 4
Number of Total Expansion Slots: 4
Shared SFP Slot: No

Interfaces/Ports
Modular: Yes
Port/Expansion Slot Details: 10 Gigabit Ethernet
Gigabit Ethernet
Stack Port: Yes
Total Number of Network Ports: 24
Uplink Port: Yes

Management & Protocols
Manageable: Yes

Media & Performance
Ethernet Technology: 10 Gigabit Ethernet
Media Type Supported: Twisted Pair
Network Technology: 10GBase-X

Miscellaneous
Environmental Certification: RoHS-5
Environmentally Friendly: Yes

Package Contents:
    -    Catalyst 9200 C9200L-24T-4X Layer 3 Switch
    -    1 x Power Supply

Network & Communication
Layer Supported: 3

Physical Characteristics
Depth: 287 mm
Height: 43.9 mm
Width: 444.5 mm

Power Description
Power Source: Power Supply
Redundant Power Supply Supported: Yes

Warranty
Limited Warranty: Lifetime
