The following rules apply when selecting the memory configuration:
- The server only supports UDIMMs
- Quantities of 1, 2, 3 or 4 DIMMs are supported.
- All DIMMs must be identical (same part number)
- When installing two DIMMs, install one in each memory channel (DIMM slots 1 and 3)
- Memory mirroring and memory rank sparing are not supported
Specifications
Product Description | Lenovo TruDDR5 - DDR5 - module - 32 GB - DIMM 288-pin - 4800 MHz / PC5-38400 - unbuffered |
Product Type | Memory module |
Capacity | 32 GB |
Memory Type | DDR5 SDRAM - DIMM 288-pin |
Upgrade Type | System specific |
Data Integrity Check | ECC |
Speed | 4800 MHz (PC5-38400) |
Features | dual rank, unbuffered |
OEM Manufacturer Equivalent Part Number | Lenovo 4X77A88512 |
