LG 65" 4K UHD High Brightness 700 nits 24/7 Digital Signage [65UH7N-E]
Key Feature
- Resolution : 3,840 x 2,160 (UHD)
- Brightness (Typ.) : 700 nit
- The carbon footprint of this product has been certified and achieved a reduction.
- Bezel : 8.9 mm (T/R/L), 12.9 mm (B)
- Interface : HDMI(2) / DP / USB 2.0 / RS232C / RJ45 / Audio / IR
- webOS Smart Platform

UHD Signage Display with LG webOS Platform and Advanced Security
* All images in this page are for illustrative purposes only.High Resolution Display
It offers a resolution that is four times higher than FHD, satisfying customers visually. Additionally, the anti-glare coating on the screen reduces screen reflection in bright lighting environments, increasing visibility and legibility, providing customers with a comfortable screen.
Convenient webOS Platform
The UH7N-E is equipped with a high-performance SoC that allows for multiple tasks to be performed without a separate media player. The webOS platform provides app development tools with an intuitive UI that enhances user convenience, enabling easy connection with external sensors and webOS partner apps to create an SI-friendly environment.
Specifications
Feature | Specification |
---|---|
Screen Size | 65" |
Panel Technology | IPS |
Back Light Type | Edge |
Aspect Ratio | 16:9 |
Native Resolution | 3,840 x 2,160 (4K UHD) |
Refresh Rate | 60 Hz |
Brightness (Typ.) | 700 nit |
Contrast Ratio | 1,100:1 |
Dynamic CR | 1,000,000 : 1 |
Color Gamut | BT709 95% |
Viewing Angle (H x V) | 178 × 178 |
Color Depth | 1.07 Billion Colors (10 bit (D)) |
Response Time | 8ms (G to G) |
Surface Treatment (Haze) | 28 % |
Life Time (Min.) | 50,000 Hrs |
Operation Hours | 24 / 7 |
Portrait / Landscape | Yes / Yes |
Bezel Color | Black |
Bezel Width | 8.9 mm (T/R/L), 12.9 mm (B) |
Weight (Head) | 24.2 kg |
Packed Weight | 30.4 kg |
Monitor Dimensions (W × H × D) | 1,450.3 x 830.3 x 29.7 mm (Without IR) |
Carton Dimensions (W × H × D) | 1,600 x 970 x 172 mm |
Handle | No |
VESA™ Standard Mount Interface | 300 × 300 mm |
Internal Memory | 16 GB |
Built-in Wi-Fi | Yes |
Sensors | Temperature, Auto Brightness, Gyro |
Local Key Operation | Yes |
Built-in Speaker | 10W x 2 |
webOS Version | 6.0 |
Local Contents Scheduling | Yes |
Group Manager | Yes |
USB Plug & Play | Yes |
Fail Over | Yes |
Image Options | Booting Logo, No Signal |
Sync Options | RS-232C Sync, Local Network Sync |
PIP / PBP | Yes (PBP: 4) |
Screen Share | Yes |
Video Tag | 4 |
Play via URL | Yes |
Rotation Options | Screen and External Input |
Gapless Playback | Yes |
Tile Mode Setting | Max. 15 × 15 |
Setting Data Cloning | Yes |
SNMP / ISM Method | Yes |
Auto Set ID | Yes |
Status Mailing | Yes |
Control Manager | Yes |
3rd Party Compatibility | Cisco Certification (TBD), Crestron Connected® |
Smart Energy Saving | Yes |
PM Mode | Yes |
Wake on LAN | Yes |
Network Ready | Yes |
Beacon | Yes |
HDMI-CEC | Yes |
SI Server Setting | Yes |
webRTC | Yes |
Pro
|
Yes |
Operation Temperature | 0 °C to 40 °C |
Operation Humidity | 10 % to 80 % |
Power Supply | AC 100-240 V ~, 50/60 Hz |
Power Type | Built-In Power |
Power Consumption (Typ./Max.) | 145 W / 200 W |
Smart Energy Saving (70%) | 101.5 W |
DPM | 0.5 W |
Power Off | 0.5 W |
Safety Certification | CB / NRTL |
EMC Certification | FCC Class “B" / CE / KC |
ePEAT (US Only) | Yes |
ErP / Energy Star | Yes (NewErP) / Yes |
ISTA6 | Yes (~'23.9, US Suffix Only) |
Carbon Trust | Yes (CO2 Measured (TBD)) |
OPS Type Compatible | No |
OPS Power Built In | No |
Software Compatibility | SuperSign CMS, SuperSign Control / Control+, SuperSign WB, SuperSign Cloud, Mobile CMS, LG ConnectedCare |
Input | HDMI In (2, 3,840 × 2,160 @ 60 Hz, HDCP 2.2/1.4), DP In (3840 × 2,160 @ 60 Hz, HDCP 2.2/1.3), RS-232C In (4 Pin Phone-jack), RJ45 (LAN) In, IR In, USB In 2.0 (Type A) (Type C, without PD function) |
Output | DP Out (3,840 × 2,160 @ 60 Hz, Input (HDMI 1/2/DP/USB-C)), Audio Out, RS-232C Out (4 Pin Phone-jack), Daisy Chain (Input HDMI, DP, USB C / Output DP) |
Languages Supported | English, French, German, Spanish, Italian, Korean, Chinese (Simplified), Chinese (Original), Portuguese (Brazil), Swedish, Finnish, Norwegian, Danish, Russian, Japanese, Portuguese (Europe), Dutch, Czech, Greek, Türkiye, Arabic |
Basic Accessories | Remote Controller, Power Cord, QSG, Regulation Book, Phone to RS-232C Gender, USB-C Cable, Cable Holder (2), AC Cord Holder (1) |
Optional Accessories | Slim Wall Mount (WB21LM A/B), Normal Wall Mount (OLW480 A/B), Wall Mount Adapter (AM-B330S) |
Tilt (Facedown) | Yes (Max 30º degree, 40ºC temperature) |
IP Rating | IP5X |
Conformal Coating (Power Board) | Yes |
