QNAP 8 Bay Desktop USB JBOD SATA Storage Expansion Enclosure

QNAPSKU: TL-D800C

Availability:

✅ In Stock at Supplier (ETA: Usually in 1-3 Business Days)

Price:
Sale price$799.00

Customer Reviews

Be the first to write a review
0%
(0)
0%
(0)
0%
(0)
0%
(0)
0%
(0)

Payment & Security

Apple Pay Google Pay Mastercard PayPal Shop Pay Visa

Your payment information is processed securely. We do not store or have access to your credit card details.
Enjoy 0% surcharge on credit card payments.

Description

The TL-D800C JBOD storage enclosure allows you to back up and expand your QNAP NAS. The TL-D800C features eight 3.5-inch SATA 6Gb/s drive bays with USB 3.2 Gen2 (10 Gbps) Type-C connectivity to provide a fast and smooth expansion solution.

  • With eight 3.5-inch SATA 6Gb/s drive bays, the TL-D800C can potentially store up to 144 TB (8 bay*18TB) raw capacity.
  • USB 3.2 Gen 2 Type-C* provides up to 10 Gb/s data transfer speeds. A USB 3.2 Gen 2 Type-C to Type-A cable is provided if your computer lacks a USB Type-C port.
  • Supports USB Attached SCSI Protocol (UASP) to provide fast file sharing and intensive data transfer.
  • Easily expand your PC storage by connecting the TL-D800C to your PC and configuring a RAID level.
  • Manage the RAID configuration using your OS or choose single-disk mode to flexibly expand your PC storage.
  • Lockable hard drive trays prevent accidental or unauthorized removal, keeping your data safe.





High-capacity storage potential

With eight 3.5-inch SATA 6Gb/s drive bays, the TL-D800C can potentially store up to 144 TB (8 bay*18TB) raw capacity – more than enough for storing all of your files and data including videos, games, ISO files, virtual machines, and much more.

High-speed USB transfer

The TL-D800C features high-speed USB 3.2 Gen 2 Type-C connectivity - with Windows® RAID 0 speed testing reaching up to 907 MB/s. Combined with UASP (USB Attached SCSI Protocol) support*, the TL-D800C provides faster file sharing and data transfer than other storage enclosures on the market.

Specifications


Drive Bay 8 x 3.5-inch SATA 6Gb/s, 3Gb/s
Drive Compatibility 3.5-inch SATA hard disk drives
2.5-inch SATA hard disk drives
2.5-inch SATA solid state drives
Audio Alert On/Off Switch
Form Factor Tower
Host Interface 1 x USB 3.2 Gen 2 Type-C
LED Indicators HDD 1-8, Status, Link, Fan error
Buttons Power switch
Dimensions (HxWxD) 188.2 × 329.3 × 281.4 mm
Weight (Net) 6.18 kg
Weight (Gross) 7.54 kg
Max. number of HDDs/SSDs supported 8
Hard Drive Type 3.5-inch SATA hard disk drives
2.5-inch SATA hard disk drives
2.5-inch SATA solid state drives
Operating temperature 0 - 40 °C (32°F - 104°F)
Storage Temperature -20 - 70°C (-4°F - 158°F)
Relative Humidity 5-95% RH non-condensing, wet bulb: 27˚C (80.6˚F)
Power Supply Unit 250W PSU, 100 - 240V
Power Consumption: Operating Mode, Typical 48.4 W
Tested with drives fully populated.
Fan Mode Switch  ✓(Auto, high, medium, low)
Fan 2 x 120mm, 12VDC
Sound Level 26.2 db(A)
System Warning Buzzer
Kensington Security Slot
