Description
Hardware Specifications | |
CPU | Dual core 1.7 GHz |
L4/L7 Hardware Acceleration Engine | |
Memory | 512 MB DDR3 |
Antenna type | 4x4 MIMO Omni-directional high-gain dipole (2.4GHz / 5GHz) |
LAN port |
|
WAN port |
|
External Ports |
|
Button and switch | WPS, USB/SD eject, Power, Reset, Wi-Fi On/Off |
Appearance | |
Size (Height x Width x Depth) | 77 mm x 280 mm x 169 mm |
Notes | The listed sizes of the RT1900ac and RT2600ac don’t include the antennas |
Weight | 0.7 kg |
Temperature | |
Operating Temperature | 5°C to 40°C (40°F to 104°F) |
Storage Temperature | -20°C to 60°C (-5°F to 140°F) |
Relative Humidity | 5% to 95% RH |
Certification |
|
Wi-Fi Certification |
|
Warranty | 2 Years |
Notes | The warranty period starts from the purchase date as stated on your purchase receipt. (Learn more) |
Others | |
AC Input Power Voltage | 100V to 240V AC |
Power Frequency | 50/ 60Hz, Single Phase |
Power Consumption* | 10.80 W (Access) 7.94 W (Idle) |
Wireless | |
IEEE 802.11ac |
|
IEEE 802.11ac wave 2 |
|
Notes | 2x2 160 MHz (contiguous 80 + 80 MHz) is not supported in Japan |
Wi-Fi encryption | WEP, WPA/WPA2-Personal, WPA/WPA2-Enterprise, WPA2/WPA3-Personal, WPA3-Personal/Enterprise, OWE |
Wi-Fi MAC address filter | |
Maximum MAC filters | 64 |
Seamless roaming | 802.11k/v/r standard support |
Beamforming | |
DFS | |
WDS | |
Schedulable Wi-Fi | |
Guest Network | |
Guest Portal | |
Customized page style | |
Connection time limit | |
Password Rotation | |
WPS 2.0 (Wi-Fi Protected Setup 2.0) | |
3G/4G Dongle & Tethering (Learn more) | |
Maximum connected devices | 100 |
Notes |
|
Primary Wi-Fi Point | |
Recommended maximum number of Wi-Fi points: |
|
Network | |
Internet connection | Dynamic IP, Static IP, PPPoE, PPTP, DS-Lite (AFTR) |
3G/4G LTE dongle | |
Android tethering | |
iPhone tethering | |
Operating mode |
|
Port forwarding | Setup via manual management or UPnP |
Maximum port forwarding rules | 64 |
Maximum UPnP rules | 64 |
Port triggering | |
Maximum port triggering rules | 32 |
Minimum port triggering timeout | 30s |
Maximum port triggering timeout | 3600s |
DMZ | |
IPv6 | IPv6 DHCP server / client, DS-Lite, 6in4, 6to4, 6rd, Dual-Stack, DHCPv6-PD, IPv6 Relay, FLET's IPv6 |
DHCP | Server/client mode, client list, MAC address reservation |
Maximum DHCP reservations | 500 |
LAN/WLAN IGMP snooping | |
VPN |
|
Policy route, Static route, Network Address Translation (NAT), PPPoE relay | |
Maximum IPv4 static routes | 100 |
Maximum IPv6 static routes | 100 |
Diagnosis tools |
|
NAT loopback (Hairpinning) | |
Safe Access | |
Parental Control | |
User Profile | 15 |
Network Profile | 2 |
Customized Internet schedule | |
Time Quota | |
IPv4/IPv6 DNS-based web filter |
|
Customized allow/block list |
|
Pause Internet | |
Reward | |
Log | |
Report | |
Security | |
Safe Search | Bing, Google, YouTube |
Threat Intelligence Database | support in IPv4 & IPv6 |
Google Safe Browsing | support in IPv4 & IPv6 |
Database auto update | Threat Intelligence Database, Google Safe Browsing, DNS-based web filter |
Traffic Control | |
Internet ban, device speed & priority | |
Application layer (L7) quality of service (QoS) | |
Maximum device rules | 64 |
Maximum application rules per device | 32 |
Traffic Monitor | |
Live view | |
Historical statistics | Daily, Weekly, Monthly, Annual |
Website history | |
Application Detection | |
Traffic Report | |
Country auto update | |
Schedulable | |
Traffic analysis period | Daily, Weekly, Monthly, Annual |
Export formats | .CSV, .HTML |
VPN Plus Server | |
VPN Plus Server | Easily create and manage secure VPN access through a web browser or client. Supports various VPN services — Site-to-Site VPN, WebVPN, SSL VPN, Remote Desktop, SSTP, OpenVPN, L2TP over IPSec, and PPTP |
Maximum Client VPN Access License | 20 |
Site-to-Site VPN | |
Maximum Site-to-Site VPN Tunnels | 10 |
Remote Desktop (RDP + VNC) | 3 |
Connection List | |
Log | |
Report | |
Threat Prevention | |
Threat Prevention | Greatly enhance the security of your router, designed to safeguard your network against internet threats |
Support | |
Package Center | |
Cloud Station Server | Sync data from multiple platforms, centralizing it on the router while easily keeping historical versions of important files |
Maximum Concurrent File Transfers | 128 |
Notes | Cloud Station ShareSync is not supported |
DNS Server | Helps users find and translate domain names into IP addresses |
Download Station | Supported download protocols: BT/HTTP/FTP/NZB/eMule |
Maximum Concurrent Download Tasks | 50 |
Maximum concurrent BT download tasks | 20 |
Media Server |
|
RADIUS Server | Provides centralized authentication, authorization, and accounting for wireless network access |
Mobile Apps | |
DS router (Android/iOS) |
|
VPN Plus (Android/iOS) | |
DS cloud (Android/iOS) | |
DS get (Android) | |
DS file (Android/iOS) | |
Management | |
Operating system | Synology Router Manager (SRM) |
Free OS upgrade | |
Anywhere access to SRM | Synology QuickConnect & Dynamic DNS (DDNS) |
Security | Firewall/SPI Firewall, DoS Protection, VPN Pass-through (PPTP, IPSec, L2TP), Auto block, SSL certificate, Security Advisor, two-factor authentication |
Wake on LAN (WOL) | |
WOL over QuickConnect | |
Maximum connected devices | 100 |
Notification | Email, SMS, push service (via DS router) |
SSH | |
SNMP | |
Configuration backup & restore | |
User account management | |
Printer server | Maximum printer: 1 |
USB/SD Card File Service | |
File System | EXT4, FAT, NTFS, HFS+ |
Access support |
|
Protocol support | Windows file service (CIFS), Mac file service (AFP), FTP/FTPS, WebDAV |
Apple Time Machine | |
Shared Folder privileges | |
Storage hibernation | |
Environment & Packaging | |
Environment | RoHS Compliant |
Packaging Content |
|
