Description
Fast storage with outstanding computing power
RS1619xs+ is a high-performance and scalable 1U rackmount NAS designed with upgradable memory and M.2 SSD cache configuration to meet the needs of modern businesses that require a flexible, reliable, and efficient storage
CPU
Quad-core up to 2.7GHz
RAM options
8GB DDR4 UDIMM, up to 64GB
High Performance
1,523 MB/s sequential reading, 162,097 iSCSI random read IOPS
Scalability
Up to 16 drives with one RX1217/RX1217RP
Variable options to boost system computing performance
Equipped with a PCIe 3.0 slot, RS1619xs+ supports installing a 10GbE/25GbE NIC for fast data transmission. Built-in M.2 2280 SSD cache slots further benefit IO-intensive tasks, such as virtualization or mail server deployment.
M.2 SSD support
Dual M.2 2280 slots supporting NVMe/SATA SSDs
10GbE/25GbE support
optional high-speed network capacity for bandwidth-intensive environments
Complete iSCSI and virtualization solutions
Synology iSCSI storage supports most virtualization solutions such as VMware vSphere, Microsoft Hyper-V, Citrix Xen Server, and OpenStack Cinder to enhance work efficiency. You can run and manage multiple virtual machines on Windows, Linux, or DSM using Virtual Machine Manager.
Next-generation file system for better data protection
The Btrfs file system introduces advanced storage technologies and optimized snapshots to prevent data corruption and reduce maintenance overhead. While ensuring high-level data integrity, it also offers flexible, efficient data protection and recovery tools.
- Flexible Shared Folder/User Quota System provides comprehensive quota control on all user accounts and shared folders
- Snapshot Replication provides schedulable and storage capacity-saving data protection with 1,024 shared folder backups and 65,000 system-wide snapshots
- File or folder level data restoration makes data recovery fast and flexible
- Automatic file self-healing detects and recovers corrupted files without user intervention
Ultimate Backup Solution
RS1619xs+ integrates various backup applications into an intuitive user interface, offering durable storage technologies to safeguard your valuable data on any device.
Active Backup for Business
Centralize backup tasks for VMware, Windows, and file servers. Restore whatever you want fast and reliably when needed.
Hyper Backup
Comprehensively back up your data to a local shared folder, an external device, another Synology NAS, an rsync server, or a public cloud to ensure data safety.
Drive Package
Safeguard your computer with Synology Drive Client. Effortlessly perform real-time data backups and point-in-time file recovery.
Active Backup for
Microsoft 365 / Google Workspace
Protect corporate data stored on the cloud. On-premise backup solution with a centralized dashboard. Optimize storage efficiency with single instancing and block-level deduplication technology.
Digital asset protection
Powered by Synology DiskStation Manager (DSM), Synology NAS offers advanced security measures to protect against sudden data loss and potential security holes.
Security Advisor
Analyze system settings, password strength and network preferences, and remove any possible malware.
AppArmor
A kernel-level enhancement that blocks malicious programs from accessing unauthorized system resources.
AES 256-bit encryption
Encrypt shared folders and network data transmission to avoid unauthorized data access.
2-step verification
Prevent others from logging in to your DSM by generating a six-digit one-time password (OTP) on your mobile device.
Powered by Synology DiskStation Manager
DSM UI
Award-winning operating system with an intuitive user interface and powerful capabilities.
Public Cloud Integration
Back up and synchronize data easily between public cloud accounts and your NAS.
Synology High Availability
Seamless transition between clustered servers in the event of a server failure to minimize the impact on applications.
Snapshot Replication
Schedulable and instantaneous data protection of shared folders and iSCSI LUNs for quick disaster recovery.
Virtual Machine Manager
Run various operating systems in isolated sandboxes. Seamlessly clone, store, and migrate virtual machines.
Security
Shield your Synology NAS from the most sophisticated threats with industry-leading security solutions.
Performance backed by Synology drives
Engineered to handle intensive 24/7 workloads, Synology drives consistently deliver top-grade performance.
Specifications
CPU
|
CPU Model | Intel Xeon D-1527 |
---|---|---|
CPU Quantity | 1 | |
CPU Architecture | 64-bit | |
CPU Frequency | 4-core 2.2 (base) / 2.7 (turbo) GHz | |
Hardware Encryption Engine (AES-NI) | ✓ | |
Memory
|
System Memory | 8 GB DDR4 ECC UDIMM |
Memory Module Pre-installed | 8 GB (8 GB x 1) | |
Total Memory Slots | 4 | |
Maximum Memory Capacity | 64 GB (16 GB x 4) | |
Notes |
|
|
Storage
|
Drive Bays | 4 |
Maximum Drive Bays with Expansion Unit | 16 (RX1217/RX1217RP x 1) | |
M.2 Drive Slots | 2 (NVMe & SATA) | |
Compatible Drive Type* (See all supported drives) |
|
|
Hot Swappable Drive* | ✓ | |
Notes |
|
|
External Ports
|
RJ-45 1GbE LAN Port | 4 (with Link Aggregation / Failover support) |
USB 3.2 Gen 1 Port* | 2 | |
Expansion Port | 1 | |
Notes | The USB 3.0 standard was renamed to USB 3.2 Gen 1 by the USB Implementers Forum (USB-IF) in 2019. | |
PCIe
|
PCIe Expansion | 1 x Gen3 x8 slot (x8 link) |
File System
|
Internal Drives |
|
External Drives |
|
|
Notes | exFAT Access can be installed for free from Package Center in DSM 7.0. In DSM 6.2 or earlier versions, exFAT Access needs to be purchased in Package Center. | |
Appearance
|
Form Factor (RU) | 1U |
Size (Height x Width x Depth) | 44 mm x 480 mm x 518.6 mm | |
Weight | 8.16 kg | |
Rack Installation Support* | 4-post 19" rack (Synology Rail Kit - RKM114/RKS-02) | |
Notes | The rail kit is sold separately | |
Others
|
System Fan | 40 mm x 40 mm x 2 pcs |
Fan Speed Mode |
|
|
Power Recovery | ✓ | |
Noise Level* | 39.3 dB(A) | |
Scheduled Power On / Off | ✓ | |
Wake on LAN / WAN | ✓ | |
Power Supply Unit / Adapter | 150 W | |
Redundant Power Supply | ✓ | |
AC Input Power Voltage | 100V to 240V AC | |
Power Frequency | 50/60 Hz, Single Phase | |
Power Consumption | 68.68 W (Access) 34.78 W (HDD Hibernation) |
|
British Thermal Unit | 234.35 BTU/hr (Access) 118.67 BTU/hr (HDD Hibernation) |
|
Notes |
|
|
Temperature
|
Operating Temperature | 5°C to 35°C (40°F to 95°F) |
Storage Temperature | -20°C to 60°C (-5°F to 140°F) | |
Relative Humidity | 5% to 95% RH | |
Certification
|
|
|
Warranty
|
5 Years | |
Notes | The warranty period starts from the purchase date as stated on your purchase receipt. (Learn more) | |
Environment
|
RoHS Compliant | |
