Description
AC1200 Wireless Dual Band Router [AC10]
- High-Speed Wi-Fi – Stream with fast and stable connections, reaching speeds up to 1167 Mbps (300 Mbps on the 2.4 GHz band and 867 Mbps on the 5 GHz band)
- 4 High-Gain External Antennas – Receive strong Wi-Fi signals in every corner of your home
- Easy Installation – Set up in minutes guided by an intuitive web UI
- Active Parental Controls – Protect your family by setting appropriate access policies for responsible, safe internet use
- IPTV and IPv6 Supported
Specifications
Wireless Standards and Frequencies
-
Wireless Standards:
- IEEE 802.11ac/n/a (5 GHz band)
- IEEE 802.11b/g/n (2.4 GHz band)
-
Frequencies:
- 2.4 GHz
- 5 GHz
Signal Rate
- 2.4 GHz Band: Up to 300 Mbps
- 5 GHz Band: Up to 867 Mbps
Reception Sensitivity
-
2.4 GHz Band:
- 11g 6Mbps: -96dBm
- 11g 54Mbps: -78dBm
- 11n HT40 MCS7: -74dBm
- 11n HT20 MCS7: -71dBm
-
5 GHz Band:
- 11a 6Mbps: -97dBm
- 11a 54Mbps: -79dBm
- 11ac VHT20 MCS8: -74dBm
- 11ac VHT40 MCS9: -70dBm
- 11ac VHT80 MCS9: -65dBm
Transmission Power
- 2.4 GHz: < 20dBm (EIRP)
- 5 GHz: < 23dBm (EIRP)
Wireless Security
- WEP
- WPA / WPA2
- WPA-PSK / WPA2-PSK
Wireless Functions
- Enable/Disable Wireless Radio
- WMM (Wi-Fi Multimedia)
Hardware Specifications
- Dimensions: 4.5 × 3.7 × 1.0 inches (114 × 94 × 26 mm)
- Button: Reset/WPS Button
- External Power Supply: 9V/0.85A
- Antenna Type: 4× 5 dBi Fixed Omni-Directional Antennas
Ethernet Ports
- WAN Port: 1× 10/100 Mbps
- LAN Ports: 2× 10/100 Mbps
