5 GHz, 34 dBi antenna ideal for long range Point-to-Point (PtP) links.
2 x 2 dual-polarity performance
Robust mechanical design for outdoor application use
Secure pole-mounting
Compatible with airFiber 5XHD
Specifications
Dimensions | 1050 x 1050 x 421 mm (41.34 x 41.34 x 16.57") |
Weight | With Mount: 13.5 kg (29.76 lb) |
Frequency | 5.1 - 5.8 GHz |
Gain | 34 dBi |
Max. VSWR | 1.4:1 |
Wind Survivability | 200 km/h (125 mph) |
Wind Loading | 1,779 N @ 200 km/h (400 lb @ 125 mph) |
Polarization | Dual Linear |
F/B Ratio | 42 dB |
ETSI Specification | EN 302 326 DN2 |
Mounting | Universal Pole Mount, airFiber Radio Bracket, and Weatherproof RF Jumpers Included |
