Description
Overview
- Seamlessly integrates with RocketM radios
- Remarkable cross-polarization isolation
- Intelligent QoS: Priority is given to voice/video for seamless streaming
- Scalability: High capacity and scalability
- Long Distance: Capable of high-speed, carrier-class links
- Up to 100 airMAX clients can be connected to an airMAX sector antenna
Specifications
- Seamlessly integrates with RocketM radios
- Remarkable cross-polarization isolation
- Intelligent QoS: Priority is given to voice/video for seamless streaming
- Scalability: High capacity and scalability
- Long Distance: Capable of high-speed, carrier-class links
- Up to 100 airMAX clients can be connected to an airMAX sector antenna
Specifications
Frequency Range |
5.15 to 5.85 GHz
|
Gain |
18.6 to 19.1 dBi
|
Hpol Beamwidth |
123° (6 dB)
|
Vpol Beamwidth |
123° (6 dB)
|
Beamwidth |
Electrical: 4°
|
Electrical Downtilt |
2°
|
VSWR (Voltage Standing Wave Ratio) |
1.5:1
|
Wind Survivability |
125 mph
|
Wind Loading |
20 lbf @ 100 mph
|
Polarization |
Dual-Linear
|
Cross-pol Isolation |
28 dB Min
|
ETSI Specification |
EN 302 326 DN2
|
Dimensions |
27.55 x 5.31 x 2.87" (700 x 135 x 73 mm)
|
